X-Ray Imaging Services
Advanced X-Ray Imaging at Our Oswestry Facility
IS Fusion Ltd provides advanced X-ray imaging inspection services from its manufacturing facility in Oswestry, supporting customers with high-quality inspection, analysis and fault detection services for the electronics manufacturing sector.
Using the cutting-edge Seamark PCB X5600 X-Ray Inspection System, IS Fusion offers powerful, high-resolution X-ray inspection capabilities designed to detect hidden soldering and component defects that traditional inspection methods cannot identify.
The system is ideally suited for printed circuit board (PCB) assemblies, semiconductor devices, LED applications, automotive electronics and a wide range of industrial electronic components.
Precision X-Ray Inspection Technology
The Seamark PCB X5600 is recognised as one of the best-selling X-ray inspection systems in the European market, combining precision imaging, advanced automation and competitive operating costs within a compact footprint.
Equipped with a high-performance 90KV X-ray source and flat-panel detector, the X5600 delivers exceptional image clarity and inspection accuracy for identifying solder voiding, cold solder joints, bridge defects, bonding wire issues and other critical manufacturing defects.
This gives customers access to detailed non-destructive inspection capabilities, helping to identify faults and quality issues that may not be visible through traditional inspection methods.
The system is capable of fully automated inspection routines tailored to customer requirements, including identification of cracks, broken wires, component offset, dimensional inconsistencies, solder defects, and quantity verification.
Key Features of the Seamark PCB X5600
– High-resolution X-ray imaging for detailed inspection analysis
– Inspection capability for sample sizes up to 280 x 320mm
– Integrated Windows 10 operating system
– Compact footprint with integrated peripheral equipment
– Three operating modes: Slow, Constant and Fast
– Keyboard-controlled X, Y and Z axis movement with angle adjustment
– Large navigation window with colour image navigation
– Automatic brightness, contrast, gain and exposure adjustment
– Integrated anti-collision protection system
– Automatic BGA diameter measurement and void ratio calculation
– Infrared automatic navigation and positioning for rapid target selection
– Customisable automated defect detection algorithms.
Supporting a Wide Range of Industries
The X-ray imaging service is suitable for a broad range of applications and industries, including:
– Surface Mount Technology (SMT)
– Semiconductor manufacturing
– BGA and CSP inspection
– Flip-chip analysis
– LED production
– Automotive electronics
– Battery manufacturing
– Aluminium die casting
– Ceramics and moulded plastics
– Photovoltaic and solar technologies.
By investing in advanced inspection capabilities, IS Fusion Ltd supports manufacturers in improving product reliability, reducing defects and maintaining high standards of quality control throughout the production process.
